Graphic Customization Aluminium Profile Aluminium Profile High Power LED Aluminum Extrusion Insert Fin Heat Sink Aluminum Profile
We have built the company's innovation system with the aim of market demand and improved the integration of our Aluminum Floor Expansion Joint Cover, aluminium extrusion 4040, aluminum window frame extrusions industry chain. No matter in the product design and production or in the process of sales and service, we always adhere to customer-oriented and meet the requirements of customers with novel and unique products and high-quality and efficient service. Our products not only enjoy a high reputation at home, but also very popular in the international markets. We have established a strict product quality control system and a complete product after-sales service system. Since the establishment of the company, we rely on the feedback of market information and the close cooperation of scientific research departments to continuously develop new products.
Product Description
Aluminium heat sink round are cost-effective solutions for the majority of electronic cooling applications. Extrusion profiles enable engineers to either select or start their design from a unique extrusion profile for the cooling solution. Applications can be for LED, IGBT, and IC devices or a wide range of other packages for electronics. Aluminium heat sink or aluminium extruded heat-sinks are mainly three types:
◆ Flat wide shape,or a fish bone-shaped comb-shaped;
◆ Round or oval-shaped;
◆ Branching shape.
Technical Parameter
Material | 6000 series Aluminium Alloy |
Temper | T5, T6 |
Size / Thickness | Profiles thickness : 0.8 to 5.0mm |
Fabrication Process | Chamfering, Punching, Counterboring, Cutting (Sawing), Deburring, Slotting, Drilling (CNC), Machining, Stamping (High Speed), Tapping, Precise Cutting, Milling (CNC) |
Application | For Heat sinks For car amplifier enclosure |
Material Introduction
Aluminium Alloy Chemical Composition | ||
Alloy | 6063 (%) | 6061 (%) |
Si | 0.2-0.60 | 0.4-0.8 |
Fe | 0.35 | 0.70 |
Cu | 0.10 | 0.150-.40 |
Mn | 0.10 | 0.15 |
Mg | 0.45-0.90 | 0.80-1.20 |
Cr | 0.10 | 0.04-0.35 |
Zn | 0.10 | 0.25 |
Ti | 0.10 | 0.15 |
Al | Remainder | Remainder |
Tensile strength | σ b (Mpa): ≥ 250 | σb (MPa)：≥180 |
Elongation stress | σ p0.2 (Mpa): ≥ 110 | σ p0.2 (Mpa): ≥ 110 |
Elongation | δ 5 (%): ≥ 7 | δ5 (%)：≥14 |
Aluminum 6063-T5, k = 201 W/mK (most common)
Aluminum 6061-T5, k =167 W/mK
Categories
Item No. | Section | Material | Diameter(mm) | Perimeter(mm) | Area(mm²) | Weight(kg/m) |
H39-010 |
| 6063-T5 | φ100±0.5 | 2252 | 2763.4 | 7.6 |
H39-002 |
| 6063-T5 | φ100±0.3 | 704.1 | 374.4 | 1.03 |
H39-003 |
| 6063-T5 | φ65±0.4 | 1078 | 596.4 | 1.64 |
H39-006 |
| 6063-T5 | φ75±0.5 | 1497.5 | 770.1 | 2.12 |
H39-007 |
| 6063-T5 | φ100±0.5 | 2367.3 | 2767.7 | 7.61 |
H39-008 |
| 6063-T5 | φ75±0.5 | 1744 | 1029.2 | 2.83 |
H39-009 |
| 6063-T5 | φ100±0.5 | 2273 | 1234.2 | 3.4 |
Product Display
We guarantee to improve Graphic Customization Aluminium Profile Aluminium Profile High Power LED Aluminum Extrusion Insert Fin Heat Sink Aluminum Profile and continue to improve through continuous innovation, hard research and development, and commitment to pursue excellence. We strive to provide a solid foundation for the company's future capacity upgrade and a broad platform and space for future sustainable development. We are never satisfied with the status quo, always have a corporate vision in mind, and constantly set new goals and new benchmarks.
