Aluminum T Track Extrusion
Product Description
These high-quality aluminium sliding door tracks are an important complement to any commercial or residential interior. Metal tracks are drilled with modern top suspension designs, providing a variety of options, such as room partitions, partitions, storage walls, cabinets and wardrobe doors. The modern fashion design of track systems eliminates the need for ugly floor tracks and passages and enables minimalist specifications for architects, decorators and engineers around the world.
Technical Parameter
Chemical Composition of Aluminum Extrusion Profiles | |||||
Alloy | 6063 | 6061 | 6060 | 6005 | |
Si | 0.2-0.6 | 0.4-0.8 | 0-0.6 | 0-0.9 | |
Mg | 0.45-0.9 | 0.8-1.2 | 0.35-0.6 | 0.4-0.6 | |
Fe | ＜0.35 | ＜0.7 | 0.1-0.3 | 0.35 | |
Cu | ＜0.1 | 0.15-0.4 | ≤0.1 | 0.1 | |
Mn | ＜0.1 | ＜0.15 | ≤0.1 | 0.1 | |
Zn | ＜0.1 | ＜0.25 | ≤0.15 | 0.1 | |
Cr | ＜0.1 | 0.04-0.35 | ≤0.05 | 0.1 | |
Ti | ＜0.1 | ＜0.15 | ＜0.1 | 0.1 | |
Impurity | Unit | ＜0.05 | ＜0.05 | ＜0.05 | ＜0.05 |
Total | ＜0.15 | ＜0.15 | ＜0.15 | ＜0.15 | |
Al | Remainder | Remainder | Remainder | Remainder | |
Technical Data of Aluminum Extrusion Profiles | ||||||
Alloy | Temper | Thickness | Tensile | Yield | Vickers | Webster |
Strength | Strength | Hardness | Hardness | |||
6005 | T6 | ≤5 | ≥270MP | ≥225MP |
|
|
T6 | 5＜e≤10 | ≥260MP | ≥215MP |
|
| |
T6 | 10＜e≤25 | ≥250MP | ≥200MP |
|
| |
6060 | T6 | ≤3 | ≥190MP | ≥150MP |
|
|
T6 | 3＜e≤25 | ≥170MP | ≥140MP |
|
| |
6061 | T6 |
| ≥265MP | ≥245MP | HV≥58 | HW≥8 |
6063 | T5 |
| ≥160MP | ≥110MP | HV≥58 | HW≥8 |
T6 |
| ≥205MP | ≥180MP | HV≥58 | HW≥8 | |
Sectional drawing
Features
◆Closed track: suitable for partition or partition, track system is very suitable for closet, cabinet or room sliding and pocket doors.
◆High quality aluminium material: High quality sliding door track is suitable for commercial and residential indoors.
◆Multifunctional Track: Mill finished metal hardware suite is very suitable for double fold doors up to 50 pounds and multi-fold doors up to 30 pounds.
◆Floor less track: Drilling holes are designed with modern top suspension. This door roller track eliminates floor passages and achieves a clean, modern appearance.
Transportation
Packaging | ●Covered and wrapped by kraft paper ●Self adhesive film packed or then shrinkage film wrapped in bundle ●Hold by plastic bag then shrinkage film wrapped in bundle ●Custom requirements are available |
Payment term | T/T 30%deposit&T/T 70% against copy of B/L,L/C |
FAQ
Q1.How is OEM&ODM service
A:Our company owns extruding production lines, surface treatment production line. And we have professional engineers that help you analyse the design.
Q2.How can you guarantee the quality
A:Before mass production, we will test the mould till its quality pass.Each product can be tested before delivery, and the test report can be issued, the video screen of the testing product can be sent to the customer,or test through video chat.
