Extruded T Slot Aluminum
t-slot-profile7
t-slot-profile8

Extruded T Slot Aluminum

Compared to steel materials,Extruded T Slot Aluminum is tough enough for daily purposes.One key factor of this product is durable because of corrosion resistance.It naturally forms a protective layer and prevent rust from happening.No need to spend extra time for protection.For the long run,you will never replace them if product never rust,which leads to a cost-effective and efficient solution.

Send Inquiry

Product Introduction

Product Description

T-slot can be assembled to construct cars,safety enclosures,work tables,etc. they come in a standard satin or clear anodized finish. Our aluminum T slot is attractive, durable, and easy to install. All of our extruded aluminum frames are non-magnetic, have a high resistance to corrosion and are always easy to machine and be replaced.

Technical Parameter

Chemical Composition of Aluminum Extrusion Profiles
Alloy		6063	6061	6060	6005
Si		0.2-0.6	0.4-0.8	0-0.6	0-0.9
Mg		0.45-0.9	0.8-1.2	0.35-0.6	0.4-0.6
Fe		＜0.35	＜0.7	0.1-0.3	0.35
Cu		＜0.1	0.15-0.4	≤0.1	0.1
Mn		＜0.1	＜0.15	≤0.1	0.1
Zn		＜0.1	＜0.25	≤0.15	0.1
Cr		＜0.1	0.04-0.35	≤0.05	0.1
Ti		＜0.1	＜0.15	＜0.1	0.1
Impurity	Unit	＜0.05	＜0.05	＜0.05	＜0.05
Impurity	Total	＜0.15	＜0.15	＜0.15	＜0.15
Al		Remainder	Remainder	Remainder	Remainder

Technical Data of Aluminum Extrusion Profiles
Alloy	Temper	Thickness	Tensile	Yield	Vickers	Webster
Alloy	Temper	Thickness	Strength	Strength	Hardness	Hardness
6005	T6	≤5	≥270MP	≥225MP
	T6	5＜e≤10	≥260MP	≥215MP
	T6	10＜e≤25	≥250MP	≥200MP
6060	T6	≤3	≥190MP	≥150MP
6060	T6	3＜e≤25	≥170MP	≥140MP
6061	T6		≥265MP	≥245MP	HV≥58	HW≥8
6063	T5		≥160MP	≥110MP	HV≥58	HW≥8
6063	T6		≥205MP	≥180MP	HV≥58	HW≥8

Sectional drawing

Extruded T Slot Aluminum

Features

◆Lightweight.one-third the weight of iron,steel, copper and brass.

◆Non-sparking.Aluminium does not emit spark.Ideal solution related to explosive and electric materials

◆Non-combustion.It will not burn even if encounter high temperature.

Factory View

After sales service

We will follow up on the quality of our products and try our best to provide quality after-sales service to ensure the interests of our customers. If the product has quality problems, we will accept the return and exchange within one month, or make a batch of materials to be delivered to the customer. We will also negotiate the freight and partial deduction with the customer according to the specific situation.

FAQ

Q1.How can you ensure high quality?

A:We have many years of technical experience, and have strict quality inspection and perfect after-sales service, as well as many professional certifications including ISO9001:2008, ISO10012，etc.

Q2.What kind of surface treatments can your company do ?

A:Our mainly surface treatments including Anodized , Powder coated , Wood grain, Polished, Brushed, Electrophoresis ,Mill finish , Sand brusting etc.

Q3.Can you give us samples before mass production?

A:Of course, if you need it, we can provide it. This also makes it easy to ensure that the product meets the size and functional requirements.
