Aluminium Formwork Accessories

Aluminium Formwork Accessories are specialized components for modular aluminum alloy building formwork systems. Made from 6000 series deformed aluminum alloy, they're manufactured through hot extrusion, precision machining, and surface treatment. They mainly help connect and join formwork panels, lock them in place, reinforce corners, and support load transfer.
Send Inquiry
Product Introduction

Technical parameter



1. Chemical Composition of Aluminium Substrate (wt%)

Compliant with GB/T 3190 standard, made of mainstream 6000-series construction-grade aluminium alloys.

Alloy Grade Si Mg Fe Cu Single Impurity Total Impurities Al
6063 0.2–0.6 0.45–0.9 <0.35 <0.1 <0.05 <0.15 Remainder
6061 0.4–0.8 0.8–1.2 <0.7 0.15–0.4 <0.05 <0.15 Remainder



2. Mechanical Properties of Substrate

Compliant with GB/T 6892 standard, available in T5 and T6 tempers.

Alloy Grade Temper Tensile Strength Yield Strength Vickers Hardness Webster Hardness
6063 T5 ≥160 MPa ≥110 MPa HV≥58 HW≥8
6063 T6 ≥205 MPa ≥180 MPa HV≥58 HW≥8
6061 T6 ≥265 MPa ≥245 MPa HV≥58 HW≥8



3. Common Core Accessory Specifications

Accessory Name Common Specifications (mm) Main Material
Pin Φ16×50 ~ Φ16×195 Q235 steel / Aluminium alloy
Tie Rod φ18 ~ φ27 45# steel
Connecting Corner Bracket Fits 65mm rib height formwork 6063-T5 aluminium alloy
Adjustable Steel Prop Outer tube Φ60×2.5, inner tube Φ48×2.5 Q235 steel



Product Features

◆All panels are clearly labeled at the factory to ensure they are easily identifiable on site and can be successfully installed using a template modulation map.

◆Simplicity.The simplicity of the aluminum formwork and the repeatability of the assembly process make it possible to precisely program the construction sequence and thus the cycle time in advance. In addition, this enables unskilled labor to work with the template, thereby reducing the burden of skilled labor shortages.

Aluminium Formwork Accessories
Aluminium Formwork Accessories

Core molding

Using a hot extrusion process, aluminum rods heated to a plastic state are high-pressure extruded through custom molds to create long profiles with uniform cross-sections, formed in one piece without seams.

01

Corrosion-resistant

Aluminium formwork accessories use the most common process, forming a hard and dense oxide layer on the surface that's scratch- and wear-resistant, making them perfect for outdoor, humid, and other tough working environments.

02

Stable Structure

Made through mold hot extrusion molding, it has no seams or weld points, giving it strong overall integrity. It's great at resisting bending and impact, with precise dimensional tolerance control.

03

Flexible customization

Supports customizing cross-section shapes, size specifications, and surface treatments based on project needs. It can fit standard flat templates as well as special structures like bay windows and stairs.

04


Application scenarios

product-496-372
product-496-372
product-496-372
product-496-372

Residential Buildings: High-rise apartments, affordable housing, and other standardized projects, designed for formwork assembly and fixing, can be reused frequently, speeding up construction and reducing costs.


Commercial & Public Buildings: Offices, hospitals, schools, etc., adaptable to stairs, bay windows, and other irregular structures, with high forming precision and low construction noise.


Infrastructure & Municipal Projects: Bridges, tunnels, utility corridors, etc., weather- and corrosion-resistant, suitable for outdoor/underground conditions, with fast modular assembly.


Prefabricated Buildings: Production of PC prefabricated components and on-site assembly, ensuring high-precision and consistent dimensions, reusable.



Why choose us



Aluminium Formwork Accessories

Years of Industry Experience: Focused on custom aluminum extrusion for the construction and industrial sectors, with mature capabilities in die accessories development and large-scale production.


Full In-House Process Control: From mold development, extrusion forming, CNC machining to anodized surface treatment, the entire process is self-owned, ensuring stable delivery times and better cost-performance.



Comprehensive Certifications: Products have passed multiple international certifications including CE, SGS, and ROHS, with traceable quality, suitable for various domestic and international engineering project standards.



High Customization Flexibility: We have both standard profile stock and full customization options, capable of producing exclusive molds based on client drawings and operational requirements.



Rich Surface Finishes: With our own anodizing workshop, we offer a variety of wear-resistant finishes including natural metal colors and colored options, matching different project appearance and performance needs.





FAQ



Q: Do you have standard aluminum formwork accessories, or do you only do custom work?
A: We have a full range of standard aluminum formwork profiles to choose from, and our main business is providing end-to-end custom solutions. Most products can be manufactured according to the actual specifications of the project.



Q: Can you do anodizing surface treatment?
A: Yes. We have our own anodizing workshop and a professional technical team, offering various types of anodizing services. It's more cost-effective and faster than outsourcing.



Q: What surface color options are available?
A: We support anodizing in the full color spectrum. From natural metallic silver and antique bronze to all kinds of high-saturation, wear-resistant colors, we can customize to meet the visual and performance needs of different projects.
